DisplayPort 1.4 To Hdmi 2.0b Hdr Cable 2m M/m
| Introduction | |
|---|---|
| The Club3D CAC-1082 is a DisplayPortT 1.4 to HDMIT 2.0b signal converter. It features support for HDR Video quality for deep color media content playback. The DisplayPortT receiver supports up to 5,4 Gbps per lane over 4 lanes. The HDMIT output is fully compliant to HDMIT specification version 2.0b. Supports up to 4K UHD Resolutions The CAC-1082 supports UHD resolutions up to 4096 x 2160p at 60Hz. Color Formats It supports RGB/YCbCr video color formats with a color depth of 16bpc (or 48 bits per pixel) as long as it fits within the DisplayPortT and HDMIT link bandwidth. The CAC-1082 also supports pixel encoding conversion from RGB or YCbCr 4:4:4 to YCbCr 4:2:0 and YCbCr 4:2:0 pass-trough function. In addition HDR with deep color up to 12Bpc at 4K 60Hz is supported through the conversion of RGB/YCbCr 4:4:4 over DP link to YCbCr 4:2:0 on the HDMIT output with a horizontal expansion to CEA timings. Note: For HDR to function, the source system needs to support DisplayPortT 1.4 and the screen needs to have support for HDR and / or HDMIT 2.0 a or b. |
No options for this product
